NMB -MAT 5920FT-D5W-B60

Price 1750 INR/ Piece

Get a Price/Quote

MOQ : 2 Pieces

NMB -MAT 5920FT-D5W-B60 Specification

Blade Material
Plastic

Size
172x150x51 mm

Type
Cooling Fan

Installation Type
Panel Mount

Power
22.8W

Power Source
DC Powered

Voltage
24V DC

Energy Efficiency Rating
Not Rated

Speed Mode
Single

Blade Diameter
172 mm

No. Of Blades
7 Blades

Color
Black

Material
Plastic

Remote Operated
No

About NMB -MAT 5920FT-D5W-B60

The NMBMAT 5920FTD5WB60 is a highperformance DC axial cooling fan designed primarily for industrial and commercial applications Operating at 24 V DC this robust fan provides efficient airflow in large enclosures server racks power electronics and other heatsensitive systems Its large frame and durable construction make it suited for continuous duty highairvolume cooling tasks

Built with precision by NMBMAT a brand of MinebeaMitsumi this model offers rugged reliability dualball bearings or equivalent heavyduty bearing system a sturdy aluminiumplastic housing and optimized impeller for high static pressure and long life

Advanced Airflow for Effective Cooling

With an impressive airflow of 199.1 CFM, the 5920FT-D5W-B60 model ensures ample cooling for sensitive machinery and electronic enclosures. Its 7-blade design, combined with the robust ball bearing system, promotes steady and effective performance even in continuous operation scenarios. This fan is ideal for systems that require reliable and high-volume air movement.

Built to Endure Demanding Conditions

Engineered with a PBT UL94V-0 thermoplastic frame and durable plastic blades, this cooling fan withstands challenging industrial environments. The impressive life expectancy of 40,000 hours at 60C reduces maintenance needs, providing dependable service in ambient temperatures ranging from -10C to +70C. Its ball bearing design further enhances durability under extended use.

Easy and Versatile Installation

The NMB-MAT 5920FT-D5W-B60 features a panel mount installation type, allowing for straightforward integration into various applications. The lead wires connector simplifies electrical connections, making the setup process efficient for manufacturers, suppliers, and end users alike. Its standardized dimensions ensure compatibility with many cooling systems.

FAQ's of NMB -MAT 5920FT-D5W-B60:

Q: How can I install the NMB-MAT 5920FT-D5W-B60 cooling fan?

A: The fan uses a panel mount design, enabling straightforward integration into cabinets or enclosures. Secure it using the provided mounting holes, then connect power through the lead wires to your 24V DC power source.

Q: What are the main benefits of choosing a ball bearing fan for industrial equipment?

A: Ball bearing fans, like the 5920FT-D5W-B60, offer longer operational life, durability in various orientations, and reliable performance at higher operating temperatures compared to sleeve bearing counterparts.

Q: When should I consider replacing or maintaining this cooling fan?

A: This fan is designed for a life expectancy of up to 40,000 hours at 60C. Regular checks for noise, airflow, and dust accumulation are recommended, and consider replacement if performance diminishes before reaching its expected lifespan.

Q: Where is the best environment to use the 5920FT-D5W-B60 model?

A: The fan performs optimally in industrial setups, electronic cabinets, or equipment requiring efficient cooling within -10C to +70C. Its durable build supports use in demanding applications where consistent airflow is critical.

Q: What process should I follow to connect the lead wires properly?

A: Ensure your power supply matches the 24V DC rating. Strip the lead wires, connect them to the corresponding terminals or power source, and secure connections with appropriate insulating materials to maintain safety and reliability.

Q: How does the thermoplastic PBT frame benefit the application?

A: The PBT UL94V-0 thermoplastic frame provides high resistance to heat and flame, contributing to enhanced safety in environments prone to temperature variations or potential electrical surges.
