ADDA 12V DC AD1212LB-A7BGL Axial Cooling Fan

About ADDA 12V DC AD1212LB-A7BGL Axial Cooling Fan

The ADDA AS12048HB389B00 is a high-performance DC axial cooling fan designed for industrial machinery, telecom systems, servers, UPS systems, power supplies, and automation equipment. Equipped with dual ball bearings and PWM speed control, it delivers high airflow, excellent static pressure, and long service life for demanding cooling applications.

Brand: ADDA
Model: AS12048HB389B00
Product Type: DC Axial Cooling Fan
Fan Type: Axial Cooling Fan
Voltage: 48 V DC
Current: 1.15 A
Power: 55.2 W
Frequency: DC (Not Applicable)
Size: 120 mm 120 mm
Dimensions (L W H): 120 120 38 mm
Dimensions (Inch): 4.72 4.72 1.50 Inch
Thickness: 38 mm
Blade Material: Plastic (PBT)
Frame Material: Glass Fiber Reinforced PBT
Bearing Type: Dual Ball Bearing
Number of Blades: 7
Rotational Speed: 6000 RPM
Airflow: 228.36 CFM
Static Pressure: 1.34 Inch-HO (34.04 mmHO)
Noise Level: 67.7 dBA
Phase: DC
Power Connection: 4 Wire (PWM + Lock Sensor)
Color: Black
Application: Industrial Equipment, Servers, Telecom Systems, UPS Systems, Power Supplies, Automation Panels, Inverters
Features: High Airflow, PWM Speed Control, Lock Sensor, Dual Ball Bearing, Long Service Life, Continuous Duty, High Static Pressure, Energy Efficient
Weight: 375 g (0.375 kg)
Package Dimensions (Inch): 6.20 6.20 2.50 Inch
Package Dimensions (cm): 15.8 15.8 6.4 cm
Country of Origin: China
